Home ProductsSugar Cone Production Line

1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates

1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates

1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates
1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates
1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates
Product Details:
Place of Origin: Guangdong guangzhou
Brand Name: STARLAND
Certification: CE
Model Number: CBIV-33*2A
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiation
Packaging Details: Container
Delivery Time: 100days
Payment Terms: T/T
Contact Now
Detailed Product Description
Name: Automatic Baking Equipment Number Of Baking Plates:: 33
Standard Cone /hour**:: 3000(23°,L110mm) Gas Consumption(kg)/ Hour:: 4-5
Place Of Origin:: China Main Motor Specification:: 1.5hp;1.1KW
Material:: Stainless Steel After Warranty Service: Video Technical Support
Local Service Location: None After-sales Service Provided: Field Installation, Commissioning And Training
High Light:

1.1KW Sugar Cone Production Line

,

33 Templates Sugar Cone Production Line

Automatic Baking Equipment , Factory Made , Top Quality ,

Multifunction , 33 Cast Iron Baking Templates.





Automatic Baking Equipment



high flexibilty.with different rolling station,a wide variety products can be produced.



batter tank and pump system,double walled to keep batter temperature stable.

steel sieve included.backflow valve stop batter to release from doser while adjustable

doser help control the wafer size.



component and parts.high quality improted bearing,accessories and minimal parts

replacement.



heart to heart rotation device,place natural rimmed cone into the same position

before packing.



durable baking plates.material is nodular cast iron.it is stable and durable.still

good in our factory after 10 years use.plates are designed and patented

in a way to maximize heat absorption.









Applicable Industries Food & Beverage Factory, Other
After Warranty Service Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location None
Showroom Location None
Video outgoing-inspection Provided
Machinery Test Report Provided
Marketing Type New Product 2021
Warranty of core components 1 Year
Core Components PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Condition New
Place of Origin China
Brand Name STARLAND
Model Number CBIV-33*2A
Voltage 220V/380V
Weight 4500KG
Dimension(L*W*H) 5000L x 2400W x 1800H
Certification CE
Warranty 1 Year
Key Selling Points High Productivity
Number of Baking Plates: 33
Standard Cone /hour**: 3000(23°,L110mm)
Place of Origin: China
Gas consumption(kg)/ hour: 4-5
name: Automatic Baking Equipment
Material: Stainless Steel
Main Motor Specification: 1.5hp ; 1.1kw







1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 01.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 1

Gas system
Auto ignition system is installed. Special design nozzle system(Utility
Model Patent#:ZL200820043449.6)
to give clear blue flames and increase energy efficiency.
Universalburner allow LPG, natural gas and some other type fuel.







1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 2

High degree of intelligence
Use smart control panel convenient and quick



1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 3



DOUBLE PANEL DOOR
The inner tank is made of zinc plate, the thermal insulation door is made of zinc

plate sandwiched with mineral wool, and the outer plate is made of stainless steel.
The use of air heat insulation convection heat preservation can reduce the temperature

of the production site and achieve the effect of energy saving.







1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 4

AUTOMATIC UNLOADING SYSTEM
Easy to use and maintain, thanks to the spring, the product can be flexibly

discharged, whether it is a flat cone or a natural side cone.



1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 5



ONE MOTOR CAN DRIVE THE ENTIRE MACHINE
It can make the oven and rolling machine system work synchrono usly with

the feed pump driven by the highprecision belt, which can produce highefficiency

and highstandard products.





1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 6



FERRIS WHEEL SYSTEM
Shorten the distance of the product from the baking template and reduce the

amount of sugar and oil.





1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 7

TURNTABLE CO-DIREC TIONAL CUP RECEIVINGSYSTEM
The new cup receiving system, with the equipment, runs on the same
horizontal line as the roll mold unwinding, to ensure that the cone
cups fall into the cup receiving groove more accurately and achieve higher
automation.







1.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 81.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 91.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 101.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 111.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 121.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 131.1KW Sugar Cone Production Line 33 Cast Iron Baking Templates 14

♦ What kind of ice cream cone your machine can make?

Our machine can make rolled ice cream cone,bowl shape cone,egg roll,and wafer biscuit cone.

♦ What’s the voltage of your machines?

380V,other voltage can be customized.

♦ 3.How can i get quotation?

Send your requirements(cone shape,size,angle,and picture)and leave your email,we will send you quotation soon.

♦ Do you have automatic ice cream cone production line?

Yes,we have several models can be choose.

♦ Which kind of payment method you can accept?

T/T.Western Union,L/C.

After Sale Service

♥ Warranty policy one year from shipment

♥ We will send you the replacement after received the broken part

♥ Evaluate the customs rish and choose safest shipping company before shipping.

♥ Follow status up time by time until the goods arrived.
